Zirconium Toughened Alumina
ZTA - Aluminum Zirconium
Zirconia toughened alumina is a composite of alumina and zirconia which leads to an increase in strength and fracture toughness as compared to other aluminas.
Increased Fracture Toughness
The high fracture toughness gives it very good edge strength and makes the material ideal for components subjected to impact loading.
Excellent Wear Resistance
During the sintering process, an extremely smooth microstructure is achieved which leads to superior wear performance.
Good Thermal Conductivity
ZTA materials provide for good dissipation of heat generated by friction.
Zirconia Toughened Alumina Ceramic Properties
All properties are at room temperature (20°C) unless otherwise stated.
| Physical Property | Units | Typical Value |
|---|---|---|
| Density | g/cc | 4.17 |
| Grain Size | μm | 6 |
| Hardness (Vickers) | GPa | 14.5 |
| Fracture Toughness | MPam^1/2 | 6 |
| Flexural Strength | MPa | 586 |
| Tensile Strength | MPa | 344 |
| Compressive Strength | MPa | 2758 |
| Elastic Modulus | GPa | 338 |
| Poisson's Ratio | - | 0.23 |
| Coefficient of Thermal Expansion | 1 x 10-6 in/in °C | 6.0 |
| Volume Resistivity | Ω-cm | 10^14 |
